External HDD Installation

You can install an additional HDD to the external HDD

slot.

Preparations:

lPrepare a 3.5” SATA HDD.

lIt is strongly recommended to use SATA standard

HDD of makers for the external HDD.

(Seagate, Western Digital, Hitachi, Samsung)

lThe recorder must be turned off before

installation.

1 Press PUSH/OPEN on the front of the recorder.

PUSH / OPEN

2 Grab the holder and extract it completely to the arrow

direction.

3 Stretch out the Right/Left hooks as shown below.

Match the hooks with External case. Push and fit the

HDD into the place completely.

HDD

External HDD case

4 Fasten the hooks as shown below.

5 Insert the external HDD to the recorder as shown

below and push it to fit into the recorder completely.

If you want to completely fix the external HDD, fix the

screws as below.
